Quick Details

  • Place of Origin: Guangdong, China (Mainland)
  • Brand Name: 3 Pin Connector Wire Harness
  • Model Number: Molex 39-01-4030 Wiring Harness
  • Application: Automobile
  • Connector Gender: Receptacle
  • Connector Housing: 0039014030 Crimp Housing
  • Pitch: 4.2mm
  • Circuit No.: 3 Pin
  • Series: Molex Mini-Fit Jr. Receptacle
  • Termination: 0039000038
  • Wire Guage: UL 2464 20AWG
  • Wire Length: 2m or custom made length
  • Insulation Material: PVC
  • Operating Temperature:: -25 to 80 ℃

Packaging & Delivery

Packaging Details PE Bag and Carton
Delivery Time 5-7 work days





Product Description



Molex Mini-Fit Jr 4.2mm Pitch 3 Pin Connector Wire Harness with Single Row 3 Circuits



 This is molex mini-fit plus connector system. This type of wire harness can deliver up to 13.0A, the Mini-Fit Plus 4.20mm pitch connector system increases power delivery for high-current applications in virtually any industry without increasing design footprints.





Product Specifications


1. Connector
Connector Gender: Female
Housing: Molex 39-01-4030 or replacement
Termination: 0039000038 or replacement



2. Cable:UL2464 20AWG*3C multi-core molding cable

Cable Construction Items:


2.1 Conductor
Sectional Area AWG/mm 21/0.178±0.008TS
material Tinned Copper
Sectional Area mm² 0.52
Stranded Diameter mm 0.94



2.2 Insulation
Material PVC
The average thickness mm 0.28
Minimum Guage mm 0.24
Color Red, Black, Yellow
Insulation Diameter mm 1.5±0.1



2.3 Shielding Covering
Screen Mode /
Sectional Area AWG/ mm /
Material /
Total Diameter mm /



2.4 Jacket
Material PVC
The average thickness mm 1.05
Minimum Guage mm 0.89
Color Black
Overall Diameter mm 5.1±0.15



3. Electrical Performance:
Rating voltage: 300V AC
Rating Current: 5A



4. Mechanical Performance:
5.1 overmolded side can withstand 5kgf axial tensile force for one minute without physical damage
5.2 overmolded side can pass the bending test in 100 cycles at each



5. Temperature
operating temperature, fixed installation: -25 to 80℃.



Service: Wiring Harness OEM
Certificate: CE, RoHS
